eCAN Registers
www.ti.com
818
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Controller Area Network (CAN)
Figure 13-25. Global Interrupt Flag 0 Register (CANGIF0)
31 24
Reserved
R-x
23 18 17 16
Reserved MTOF0 TCOF0
R-x R-0 RC-0
15 14 13 12 11 10 9 8
GMIF0 AAIF0 WDIF0 WUIF0 RMLIF0 BOIF0 EPIF0 WLIF0
R/W-0 R-0 RC-0 RC-0 R-0 RC-0 RC-0 RC-0
7 5 4 3 2 1 0
Reserved MIV0.4 MIV0.3 MIV0.2 MIV0.1 MIV0.0
R/W-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read; C = Clear; -n = value after reset
Figure 13-26. Global Interrupt Flag 1 Register (CANGIF1)
31 24
Reserved
R-x
23 18 17 16
Reserved MTOF1 TCOF1
R-x R-0 RC-0
15 14 13 12 11 10 9 8
GMIF1 AAIF1 WDIF1 WUIF1 RMLIF1 BOIF1 EPIF1 WLIF1
R/W-0 R-0 RC-0 RC-0 R-0 RC-0 RC-0 RC-0
7 5 4 3 2 1 0
Reserved MIV0.4 MIV0.3 MIV0.2 MIV0.1 MIV0.0
R/W-0 R-0 R-0 R-0 R-0 R-0
LEGEND: R/W = Read/Write; R = Read; C = Clear; -n = value after reset
Note: eCAN only, reserved in the SCC
NOTE: The following bit descriptions are applicable to both the CANGIF0 and CANGIF1 registers.
For the following interrupt flags, whether they are set in the CANGIF0 or the CANGIF1
register is determined by the value of the GIL bit in the CANGIM register: TCOFn, AAIFn,
WDIFn, WUIFn, RMLIFn, BOIFn, EPIFn, and WLIFn.
If GIL = 0, these flags are set in the CANGIF0 register; if GIL = 1, they are set in the
CANGIF1 register.
Similarly, the choice of the CANGIF0 and CANGIF1 register for the MTOFn and GMIFn bits
is determined by the MILn bit in the CANMIL register.
Table 13-22. Global Interrupt Flag Registers (CANGIF0/CANGIF1) Field Descriptions
Bit Field Value Description
31:18 Reserved Reserved. Reads are undefined and writes have no effect.
17 MTOF0/1 Mailbox time-out flag. This bit is not available in the SCC mode.
1 One of the mailboxes did not transmit or receive a message within the specified time frame.
0 No time out for the mailboxes occurred.
Note: Whether the MTOFn bit gets set in CANGIF0 or CANGIF1 depends on the value of MILn.
MTOFn gets cleared when TOSn is cleared. The TOSn bit will be cleared upon (eventual)
successful transmission/reception.
To Next Page
