System Control and Interrupts
Figure 1-71. GPIO XINTn, XNMI Interrupt Select (GPIOXINTnSEL, GPIOXNMISEL) Registers
15 5 4 0
Reserved GPIOXINTnSEL
R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
(1)
n = 1 or 2
(2)
This register is EALLOW protected. See Section 1.5.2 for more information.
Table 1-80. GPIO XINTn Interrupt Select (GPIOXINTnSEL)
(1)
Register Field Descriptions
Bits Field Value Description
(2)
15-5 Reserved Reserved
4-0 GPIOXINTnSEL Select the port A GPIO signal (GPIO0 - GPIO31) that will be used as the XINT1 or XINT2
interrupt source. In addition, you can configure the interrupt in the XINT1CR or XINT2CR
registers described in Section 1.6.5.
To use XINT2 as ADC start of conversion, enable it in the ADCTRL2 register. The ADCSOC
signal is always rising edge sensitive.
00000 Select the GPIO0 pin as the XINTn interrupt source (default)
00001 Select the GPIO1 pin as the XINTn interrupt source
. . . . . .
11110 Select the GPIO30 pin as the XINTn interrupt source
11111 Select the GPIO31 pin as the XINTn interrupt source
Table 1-81. XINT1/XINT2 Interrupt Select and Configuration Registers
n Interrupt Interrupt Select Register Configuration Register
1 XINT1 GPIOXINT1SEL XINT1CR
2 XINT2 GPIOXINT2SEL XINT2CR
(1)
n = 3, 4, 5, 6, or 7
(2)
This register is EALLOW protected. See Section 1.5.2 for more information.
Table 1-82. GPIO XINT3 - XINT7 Interrupt Select (GPIOXINTnSEL) Register Field Descriptions
(1)
Bits Field Value Description
(2)
15-5 Reserved Reserved
4-0 GPIOXINTnSEL Select the port B GPIO signal (GPIO32 - GPIO63) that will be used as the XINTn interrupt
source. In addition, you can configure the interrupt in the XINTnCR register described in
Section 1.6.5.
00000 Select the GPIO32 pin as the XINTn interrupt source (default)
00001 Select the GPIO33 pin as the XINTn interrupt source
. . . . . .
11110 Select the GPIO62 pin as the XINTn interrupt source
11111 Select the GPIO63 pin as the XINTn interrupt source
Table 1-83. XINT3 - XINT7 Interrupt Select and Configuration Registers
n Interrupt Interrupt Select Register Configuration Register
3 XINT3 GPIOXINT3SEL XINT3CR
4 XINT4 GPIOXINT4SEL XINT4CR
5 XINT5 GPIOXINT5SEL XINT5CR
6 XINT6 GPIOXINT6SEL XINT6CR
7 XINT7 GPIOXINT7SEL XINT7CR
