System Control and Interrupts
The CPU then prepares to service the interrupt. This preparation process is described in detail in
TMS320C28x DSP CPU and Instruction Set Reference Guide (literature number SPRU430). In
preparation, the corresponding CPU IFR and IER bits are cleared, EALLOW and LOOP are cleared, INTM
and DBGM are set, the pipeline is flushed and the return address is stored, and the automatic context
save is performed. The vector of the ISR is then fetched from the PIE module. If the interrupt request
comes from a multiplexed interrupt, the PIE module uses the group PIEIERx and PIEIFRx registers to
decode which interrupt needs to be serviced. This decode process is described in detail in Section
Section 1.6.3.3.
The address for the interrupt service routine that is executed is fetched directly from the PIE interrupt
vector table. There is one 32-bit vector for each of the possible 96 interrupts within the PIE. Interrupt flags
within the PIE module (PIEIFRx.y) are automatically cleared when the interrupt vector is fetched. The PIE
acknowledge bit for a given interrupt group, however, must be cleared manually when ready to receive
more interrupts from the PIE group.
1.6.2 Vector Table Mapping
On 28xx devices, the interrupt vector table can be mapped to four distinct locations in memory. In practice
only the PIE vector table mapping is used.
This vector mapping is controlled by the following mode bits/signals:
VMAP: VMAP is found in Status Register 1 ST1 (bit 3). A device reset sets this bit to 1. The state of this bit can
be modified by writing to ST1 or by SETC/CLRC VMAP instructions. For normal operation leave this bit
set.
M0M1MAP: M0M1MAP is found in Status Register 1 ST1 (bit 11). A device reset sets this bit to 1. The state of this bit
can be modified by writing to ST1 or by SETC/CLRC M0M1MAP instructions. For normal 28xx device
operation, this bit should remain set. M0M1MAP = 0 is reserved for TI testing only.
ENPIE: ENPIE is found in PIECTRL Register (bit 0). The default value of this bit, on reset, is set to 0 (PIE
disabled). The state of this bit can be modified after reset by writing to the PIECTRL register (address
0x0000 0CE0).
Using these bits and signals the possible vector table mappings are shown in Table 1-109.
(1)
Vector map M0 and M1 Vector is a reserved mode only. On the 28x devices these are used as SARAM.
Table 1-109. Interrupt Vector Table Mapping
Vector MAPS Vectors Fetched From Address Range VMAP M0M1MAP ENPIE
M1 Vector
(1)
M1 SARAM Block 0x000000 - 0x00003F 0 0 X
M0 Vector
(1)
M0 SARAM Block 0x000000 - 0x00003F 0 1 X
BROM Vector Boot ROM Block 0x3FFFC0 - 0x3FFFFF 1 X 0
PIE Vector PIE Block 0x000D00 - 0x000DFF 1 X 1
The M1 and M0 vector table mapping are reserved for TI testing only. When using other vector mappings,
the M0 and M1 memory blocks are treated as SARAM blocks and can be used freely without any
restrictions.
After a device reset operation, the vector table is mapped as shown in Table 1-110.
(1)
On the 28x devices, the VMAP and M0M1MAP modes are set to 1 on reset. The ENPIE mode is forced to 0 on reset.
(2)
The reset vector is always fetched from the boot ROM.
Table 1-110. Vector Table Mapping After Reset Operation
Vector MAPS Reset Fetched From Address Range VMAP
(1)
M0M1MAP
(1)
ENPIE
(1)
BROM Vector
(2)
Boot ROM Block 0x3FFFC0 - 0x3FFFFF 1 1 0
