www.ti.com
Peripheral Interrupt Expansion (PIE)
163
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
1.6.5 External Interrupt Control Registers
Seven external interrupts, XINT1 –XINT7 are supported. XINT13 is multiplexed with one non-maskable
interrupt XNMI. Each of these external interrupts can be selected for negative or positive edge triggered
and can also be enabled or disabled (including XNMI). The masked interrupts also contain a 16-bit free
running up counter that is reset to zero when a valid interrupt edge is detected. This counter can be used
to accurately time stamp the interrupt.
XINT1CR through XINT7CR are identical except for the interrupt number; therefore, Figure 1-91 and
Table 1-121 represent registers for external interrupts 1 through 7 as XINT nCR where n = the interrupt
number.
1.6.5.1 External Interrupt n Control Register (XINTnCR)
Figure 1-91. External Interrupt n Control Register (XINTnCR)
15 4 3 2 1 0
Reserved Polarity Reserved Enable
R-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-121. External Interrupt n Control Register (XINTnCR) Field Descriptions
Bits Field Value Description
15-4 Reserved Reads return zero; writes have no effect.
3-2 Polarity This read/write bit determines whether interrupts are generated on the rising edge or the
falling edge of a signal on the pin.
00 Interrupt generated on a falling edge (high-to-low transition)
01 Interrupt generated on a rising edge (low-to-high transition)
10 Interrupt is generated on a falling edge (high-to-low transition)
11 Interrupt generated on both a falling edge and a rising edge (high-to-low and low-to-high
transition)
1 Reserved Reads return zero; writes have no effect
0 Enable This read/write bit enables or disables external interrupt XINTn.
0 Disable interrupt
1 Enable interrupt
1.6.5.2 External NMI Interrupt Control Register (XNMICR) (Address 7077h)
Figure 1-92. External NMI Interrupt Control Register (XNMICR) — Address 7077h
15 4 3 2 1 0
Reserved Polarity Select Enable
R-0 R/W-0 R-0 R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
