Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-80. Trip-Zone Enable Interrupt Register (TZEINT)
15 8
Reserved
R -0
7 3 2 1 0
Reserved OST CBC Reserved
R-0 R/W-0 R/W-0 R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-40. Trip-Zone Enable Interrupt Register (TZEINT) Field Descriptions
Bits Name Value Description
15-3 Reserved Reserved
2 OST Trip-zone One-Shot Interrupt Enable
0 Disable one-shot interrupt generation
1 Enable Interrupt generation; a one-shot trip event will cause a EPWMx_TZINT PIE interrupt.
1 CBC Trip-zone Cycle-by-Cycle Interrupt Enable
0 Disable cycle-by-cycle interrupt generation.
1 Enable interrupt generation; a cycle-by-cycle trip event will cause an EPWMx_TZINT PIE interrupt.
0 Reserved Reserved
