www.ti.com
eQEP Registers
415
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Quadrature Encoder Pulse (eQEP)
6.10.2.3 QPOSMAX Register (Offset = 4h) [reset = 0h]
QPOSMAX is shown in Figure 6-23 and described in Table 6-8.
Return to the Summary Table.
Maximum Position Count
Figure 6-23. QPOSMAX Register
31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
QPOSMAX
R/W-0h
Table 6-8. QPOSMAX Register Field Descriptions
Bit Field Type Reset Description
31-0 QPOSMAX R/W 0h
Maximum Position Count
This register contains the maximum position counter value. Writes to
this register should always be full 32-bit writes.
Reset type: SYSRSn
