Message Mailbox
www.ti.com
784
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Controller Area Network (CAN)
Table 13-3. Addresses of LAM, MOTS and MOTO registers for mailboxes (eCAN-A)
Mailbox LAM MOTS MOT0
0 6040h-6041h 6080h-6081h 60C0h-60C1h
1 6042h-6043h 6082h-6083h 60C2h-60C3h
2 6044h-6045h 6084h-6085h 60C4h-60C5h
3 6046h-6047h 6086h-6087h 60C6h-60C7h
4 6048h-6049h 6088h-6089h 60C8h-60C9h
5 604Ah-604Bh 608Ah-608Bh 60CAh-60CBh
6 604Ch-604Dh 608Ch-608Dh 60CCh-60CDh
7 604Eh-604Fh 608Eh-608Fh 60CEh-60CFh
8 6050h-6051h 6090h-6091h 60D0h-60D1h
9 6052h-6053h 6092h-6093h 60D2h-60D3h
10 6054h-6055h 6094h-6095h 60D4h-60D5h
11 6056h-6057h 6096h-6097h 60D6h-60D7h
12 6058h-6059h 6098h-6099h 60D8h-60D9h
13 605Ah-605Bh 609Ah-609Bh 60DAh-60DBh
14 605Ch-605Dh 609Ch-609Dh 60DCh-60DDh
15 605Eh-605Fh 609Eh-609Fh 60DEh-60DFh
16 6060h-6061h 60A0h-60A1h 60E0h-60E1h
17 6062h-6063h 60A2h-60A3h 60E2h-60E3h
18 6064h-6065h 60A4h-60A5h 60E4h-60E5h
19 6066h-6067h 60A6h-60A7h 60E6h-60E7h
20 6068h-6069h 60A8h-60A9h 60E8h-60E9h
21 606Ah-606Bh 60AAh-60ABh 60EAh-60EBh
22 606Ch-606Dh 60ACh-60ADh 60ECh-60EDh
23 606Eh-606Fh 60AEh-60AFh 60EEh-60EFh
24 6070h-6071h 60B0h-60B1h 60F0h-60F1h
25 6072h-6073h 60B2h-60B3h 60F2h-60F3h
26 6074h-6075h 60B4h-60B5h 60F4h-60F5h
27 6076h-6077h 60B6h-60B7h 60F6h-60F7h
28 6078h-6079h 60B8h-60B9h 60F8h-60F9h
29 607Ah-607Bh 60BAh-60BBh 60FAh-60FBh
30 607Ch-607Dh 60BCh-60BDh 60FCh-60FDh
31 607Eh-607Fh 60BEh-60BFh 60FEh-60FFh
