www.ti.com Clocking and System Control
83
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
Figure 1-33. TIMERxTIM Register (x = 0, 1, 2)
15 0
TIM
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-32. TIMERxTIM Register Field Descriptions
Bits Field Description
15-0 TIM CPU-Timer Counter Registers (TIMH:TIM): The TIM register holds the low 16 bits of the current 32-bit count
of the timer. The TIMH register holds the high 16 bits of the current 32-bit count of the timer. The TIMH:TIM
decrements by one every (TDDRH:TDDR+1) clock cycles, where TDDRH:TDDR is the timer prescale divide-
down value. When the TIMH:TIM decrements to zero, the TIMH:TIM register is reloaded with the period
value contained in the PRDH:PRD registers. The timer interrupt (TINT) signal is generated.
Figure 1-34. TIMERxTIMH Register (x = 0, 1, 2)
15 0
TIMH
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-33. TIMERxTIMH Register Field Descriptions
Bits Field Description
15-0 TIMH See description for TIMERxTIM.
Figure 1-35. TIMERxPRD Register (x = 0, 1, 2)
15 0
PRD
R/W-0xFFFF
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-34. TIMERxPRD Register Field Descriptions
Bits Field Description
15-0 PRD CPU-Timer Period Registers (PRDH:PRD): The PRD register holds the low 16 bits of the 32-bit period. The
PRDH register holds the high 16 bits of the 32-bit period. When the TIMH:TIM decrements to zero, the
TIMH:TIM register is reloaded with the period value contained in the PRDH:PRD registers, at the start of
the next timer input clock cycle (the output of the prescaler). The PRDH:PRD contents are also loaded into
the TIMH:TIM when you set the timer reload bit (TRB) in the Timer Control Register (TCR).
Figure 1-36. TIMERxPRDH Register (x = 0, 1, 2)
15 0
PRDH
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 1-35. TIMERxPRDH Register Field Descriptions
Bits Field Description
15-0 PRDH See description for TIMERxPRD
