www.ti.com
Registers
303
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-69. Compare A High Resolution Register (CMPAHR)
15 8
CMPAHR
R/W-0
7 0
Reserved
R-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-29. Compare A High Resolution Register (CMPAHR) Field Descriptions
Bit Field Value Description
15-8 CMPAHR 00-FFh These 8-bits contain the high-resolution portion (least significant 8-bits) of the counter-compare A
value. CMPA:CMPAHR can be accessed in a single 32-bit read/write.
Shadowing is enabled and disabled by the CMPCTL[SHDWAMODE] bit as described for the CMPA
register.
7-0 Reserved Reserved for TI Test
