ePWM Submodules
www.ti.com
258
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
qualifier submodule to generate the signal as shown for EPWMxA.
• Mode 6: Bypass rising-edge-delay and Mode 7: Bypass falling-edge-delay
Finally the last two entries in Table 3-14 show combinations where either the falling-edge-delay (FED)
or rising-edge-delay (RED) blocks are bypassed.
Table 3-14. Classical Dead-Band Operating Modes
Mode Mode Description
DBCTL[POLSEL] DBCTL[OUT_MODE]
S3 S2 S1 S0
1 EPWMxA and EPWMxB Passed Through (No Delay) X X 0 0
2 Active High Complementary (AHC) 1 0 1 1
3 Active Low Complementary (ALC) 0 1 1 1
4 Active High (AH) 0 0 1 1
5 Active Low (AL) 1 1 1 1
6
EPWMxA Out = EPWMxA In (No Delay)
0 or 1 0 or 1 0 1
EPWMxB Out = EPWMxA In with Falling Edge Delay
7
EPWMxA Out = EPWMxA In with Rising Edge Delay
0 or 1 0 or 1 1 0
EPWMxB Out = EPWMxB In with No Delay
