Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-76. Dead-Band Generator Falling Edge Delay Register (DBFED)
15 10 9 8
Reserved DEL
R-0 R/W-0
7 0
DEL
R/W-0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-36. Dead-Band Generator Falling Edge Delay Register (DBFED) Field Descriptions
Bits Name Description
15-10 Reserved Reserved
9-0 DEL Falling Edge Delay Count. 10-bit counter
