Example 7-5. Conversion in Dual-Sequencer Mode Using SEQ1
Suppose seven conversions are desired from SEQ1 (i.e., inputs ADCINA2 and ADCINA3 twice, then
ADCINA6, ADCINA7, and ADCINB4 must be converted as part of the autosequenced session), then
MAX_CONV1 should be set to 6 and the ADCCHSELSEQn registers should be set to the values shown in
Table 7-6.
Conversion begins once the start-of-conversion (SOC) trigger is received by the sequencer. The SOC trigger
also loads the SEQ_CNTR bits. Those channels that are specified in the ADCCHSELSEQn registers are
taken up for conversion, in the predetermined sequence. The SEQ_CNTR bits are decremented by one
automatically after every conversion. Once SEQ_CNTR reaches zero, two things can happen, depending on
the status of the continuous run bit (CONT_RUN) in the ADCTRL1 register. See Figure 7-12 for an illustration
of the flow.
• If CONT_RUN is set, the conversion sequence starts all over again automatically (i.e., SEQ_CNTR gets
reloaded with the original value in MAX_CONV1 and SEQ1 state is set to CONV00 [See Section 7.3.3.2
for more options]). In this case, to avoid overwriting the data, you must be sure that the result registers are
read before the next conversion sequence begins. The arbitration logic designed into the ADC ensures that
the result registers are not corrupted should a contention arise (ADC module trying to write into the result
registers while you try to read from them at the same time).
• If CONT_RUN is not set, the sequencer stays in the last state (CONV06, in this example) and SEQ_CNTR
continues to hold a value of zero. To repeat the sequence on the next SOC, the sequencer must be reset
using the RST_SEQn bit prior to the next SOC.
If the interrupt flag is set every time SEQ_CNTR reaches zero (INT_ENA_SEQn = 1 and INT_MOD_SEQn =
0), you can (if needed) manually reset the sequencer (using the RST_SEQn bit in the ADCTRL2 register) in
the interrupt service routine (ISR). This causes the SEQn state to be reset to its original value (CONV00 for
SEQ1 and CONV08 for SEQ2). This feature is useful in the Start/Stop operation of the sequencer. Example 7-
5 also applies to SEQ2 and the cascaded 16-state sequencer (SEQ) with differences outlined in Table 7-5.
(1)
Values are in decimal, and x = don't care
Table 7-6. Values for ADCCHSELSEQn Registers (MAX_CONV1 Set to 6)
Bits 15-12
(1)
Bits 11-8
(1)
Bits 7-4
(1)
Bits 3-0
(1)
7103h 3 2 3 2 ADCCHSELSEQ1
7104h x 12 7 6 ADCCHSELSEQ2
7105h x x x x ADCCHSELSEQ3
7106h x x x x ADCCHSELSEQ4
