Original
(outA)
Rising Edge
Delayed (RED)
Falling Edge
Delayed (FED)
Active High
Complementary
(AHC)
Active Low
Complementary
(ALC)
Active High
(AH)
Active Low
(AL)
RED
FED
Period
www.ti.com
ePWM Submodules
259
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-30 shows waveforms for typical cases where 0% < duty < 100%.
Figure 3-30. Dead-Band Waveforms for Typical Cases (0% < Duty < 100%)
