Enhanced Quadrature Encoder Pulse (eQEP)
6.10.2.11 QWDPRD Register (Offset = 13h) [reset = 0h]
QWDPRD is shown in Figure 6-31 and described in Table 6-16.
Return to the Summary Table.
QEP Watchdog Period
Figure 6-31. QWDPRD Register
15 14 13 12 11 10 9 8
QWDPRD
R/W-0h
7 6 5 4 3 2 1 0
QWDPRD
R/W-0h
Table 6-16. QWDPRD Register Field Descriptions
Bit Field Type Reset Description
15-0 QWDPRD R/W 0h
QEP Watchdog Period
This register contains the time-out count for the eQEP peripheral
watch dog timer.
When the watchdog timer value matches the watchdog period value,
a watchdog timeout interrupt is generated.
Reset type: SYSRSn
