Serial Communications Interface (SCI)
10.14.2.4 SCILBAUD Register (Offset = 3h) [reset = 0h]
SCILBAUD is shown in Figure 10-14 and described in Table 10-10.
Return to the Summary Table.
The values in SCIHBAUD and SCILBAUD specify the baud rate for the SCI.
Figure 10-14. SCILBAUD Register
15 14 13 12 11 10 9 8
RESERVED
R-0h
7 6 5 4 3 2 1 0
BAUD
R/W-0h
Table 10-10. SCILBAUD Register Field Descriptions
Bit Field Type Reset Description
15-8 RESERVED R 0h
Reserved
7-0 BAUD R/W 0h
See SCIHBAUD Detailed Description
Reset type: SYSRSn
