Enhanced Pulse Width Modulator (ePWM) Module
Table 3-38. Trip-Zone Select Register (TZSEL) Field Descriptions (continued)
Bits Name Value Description
3 CBC4 Trip-zone 4 (TZ4) Select
0 Disable TZ4 as a CBC trip source for this ePWM module
1 Enable TZ4 as a CBC trip source for this ePWM module
2 CBC3 Trip-zone 3 (TZ3) Select
0 Disable TZ3 as a CBC trip source for this ePWM module
1 Enable TZ3 as a CBC trip source for this ePWM module
1 CBC2 Trip-zone 2 (TZ2) Select
0 Disable TZ2 as a CBC trip source for this ePWM module
1 Enable TZ2 as a CBC trip source for this ePWM module
0 CBC1 Trip-zone 1 (TZ1) Select
0 Disable TZ1 as a CBC trip source for this ePWM module
1 Enable TZ1 as a CBC trip source for this ePWM module
