www.ti.com
Message Mailbox
785
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Controller Area Network (CAN)
Table 13-4. eCAN-B Mailbox RAM Layout
MB MSGID
MSGIDL-MSGIDH
MSGCTRL
MSGCTRL - Rsvd
CANMDL
CANMDL_L - CANMDL_H
CANMDH
CANMDH_L - CANMDH_H
0 6300-6301h 6302-6303h 6304-6305h 6306-6307h
1 6308-6309h 630A-630Bh 630C-630Dh 630E-630Fh
2 6310-6311h 6312-6313h 6314-6315h 6316-6317h
3 6318-6319h 631A-631Bh 631C-631Dh 631E-631Fh
4 6320-6321h 6322-6323h 6324-6325h 6326-6327h
5 6328-6329h 632A-632Bh 632C-632Dh 632E-632Fh
6 6330-6331h 6332-6333h 6334-6335h 6336-6337h
7 6338-6339h 633A-633Bh 633C-633Dh 633E-633Fh
8 6340-6341h 6342-6343h 6344-6345h 6346-6347h
9 6348-6349h 634A-634Bh 634C-634Dh 634E-634Fh
10 6350-6351h 6352-6353h 6354-6355h 6356-6357h
11 6358-6359h 635A-635Bh 635C-635Dh 635E-635Fh
12 6360-6361h 6362-6363h 6364-6365h 6366-6367h
13 6368-6369h 636A-636Bh 636C-636Dh 636E-636Fh
14 6370-6371h 6372-6373h 6374-6375h 6376-6377h
15 6378-6379h 637A-637Bh 637C-637Dh 637E-637Fh
16 6380-6381h 6382-6383h 6384-6385h 6386-6387h
17 6388-6389h 638A-638Bh 638C-638Dh 638E-638Fh
18 6390-6391h 6392-6393h 6394-6395h 6396-6397h
19 6398-6399h 639A-639Bh 639C-639Dh 639E-639Fh
20 63A0-63A1h 63A2-63A3h 63A4-63A5h 63A6-63A7h
21 63A8-63A9h 63AA-63ABh 63AC-63ADh 63AE-63AFh
22 63B0-63B1h 63B2-63B3h 63B4-63B5h 63B6-63B7h
23 63B8-63B9h 63BA-63BBh 63BC-63BDh 63BE-63BFh
24 63C0-63C1h 63C2-63C3h 63C4-63C5h 63C6-63C7h
25 63C8-63C9h 63CA-63CBh 63CC-63CDh 63CE-63CFh
26 63D0-63D1h 63D2-63D3h 63D4-63D5h 63D6-63D7h
27 63D8-63D9h 63DA-63DBh 63DC-63DDh 63DE-63DFh
28 63E0-63E1h 63E2-63E3h 63E4-63E5h 63E6-63E7h
29 63E8-63E9h 63EA-63EBh 63EC-63EDh 63EE-63EFh
30 63F0-63F1h 63F2-63F3h 63F4-63F5h 63F6-63F7h
31 63F8-63F9h 63FA-63FBh 63FC-63FDh 63FE-63FFh
