Polarity selection
t
www.ti.com
Application of the eCAP Module
365
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Capture (eCAP)
5.6.2 Example 2 - Absolute Time-Stamp Operation Rising and Falling Edge Trigger
In Figure 5-13 the eCAP operating mode is almost the same as in the previous section except capture
events are qualified as either rising or falling edge, this now gives both period and duty cycle information,
that is: Period1 = t
3
– t
1
, Period2 = t
5
– t
3
, …and so on. Duty Cycle1 (on-time %) = (t
2
– t
1
) / Period1 x
100%, etc. Duty Cycle1 (off-time %) = (t
3
– t
2
) / Period1 x 100%, and so on.
Figure 5-13. Capture Sequence for Absolute Time-stamp With Rising and Falling Edge Detect
