Controller Area Network (CAN)
13.8.15.2 Global Interrupt Mask Register (CANGIM)
The set up for the interrupt mask register is the same as for the interrupt flag register. If a bit is set, the
corresponding interrupt is enabled. This register is EALLOW protected.
The GMIF has no corresponding bit in the CANGIM because the mailboxes have individual mask bits in
the CANMIM register.
Figure 13-27. Global Interrupt Mask Register (CANGIM)
31 18 17 16
Reserved MTOM TCOM
R-0 R/WP-
0
R/WP-
0
15 14 13 12 11 10 9 8
Reserved AAIM WDIM WUIM RMLIM BOIM EPIM WLIM
R-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0 R/WP-0
7 3 2 1 0
Reserved GIL I1EN I0EN
R-0 R/WP-0 R/WP-0 R/WP-0
LEGEND: R = Read; W = Write; WP = Write in EALLOW mode only; -n = value after reset
Table 13-23. Global Interrupt Mask Register (CANGIM) Field Descriptions
Bit Field Value Description
31:18 Reserved Reads are undefined and writes have no effect.
17 MTOM Mailbox time-out interrupt mask
1 Enabled
0 Disabled
16 TCOM Time stamp counter overflow mask
1 Enabled
0 Disabled
15 Reserved Reads are undefined and writes have no effect.
14 AAIM Abort Acknowledge Interrupt Mask.
1 Enabled
0 Disabled
13 WDIM Write denied interrupt mask
1 Enabled
0 Disabled
12 WUIM Wake-up interrupt mask
1 Enabled
0 Disabled
11 RMLIM Received-message-lost interrupt mask
1 Enabled
0 Disabled
10 BOIM Bus-off interrupt mask
1 Enabled
0 Disabled
9 EPIM Error-passive interrupt mask
1 Enabled
0 Disabled
8 WLIM Warning level interrupt mask
1 Enabled
0 Disabled
