eCAN Registers
www.ti.com
828
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Controller Area Network (CAN)
13.8.18.2.4 Time-Out Status Register (CANTOS)
This register holds the status information of mailboxes that have timed out.
Figure 13-37. Time-Out Status Register (CANTOS)
31 0
TOS31:0
R/C-0
LEGEND: R/C = Read/Clear; -n = value after reset
Table 13-33. Time-Out Status Register (CANTOS) Field Descriptions
Bit Field Value Description
31:0 TOS 31:0 Time-out status register
1 Mailbox[n] has timed out. The value in the TSC register is larger or equal to the value in the time-
out register that corresponds to mailbox n and the TOC[n] bit is set.
0 No time-out occurred or it is disabled for that mailbox.
The TOSn bit is set when all three of the following conditions are met:
1. The TSC value is greater than or equal to the value in the time-out register (MOTOn).
2. The TOCn bit is set.
3. The TRSn bit is set (in the case of a transmit mailbox).
The time-out registers are implemented as a RAM. The state machine scans all the time-out registers and
compares them to the time stamp counter value. Since all the time out registers are scanned sequentially,
it is possible that even though a transmit mailbox has timed out, the TOSn bit is not set. This can happen
when the mailbox succeeded in transmitting and clearing the TRSn bit before the state machine scans the
time-out register of that mailbox. This is true for the receive mailbox as well. In this case, the RMPn bit
can be set to 1 by the time the state machine scans the time-out register of that mailbox. However, the
receive mailbox probably did not receive the message before the time specified in the time-out register.
13.8.18.3 Behavior/Usage of MTOF0/1 Bit in User Applications
The MTOF0/1 bit is automatically cleared by the CPK (along with the TOSn bit) upon
transmission/reception by the mailbox, which asserted this flag in the first place. It can also be cleared by
the user (via the CPU). On a time-out condition, the MTOF0/1 bit (and the TOS.n bit) is set. On an
(eventual) successful communication, these bits are automatically cleared by the CPK. Following are the
possible behaviors/usage for the MTOF0/1 bit:
1. Time-out condition occurs. Both MTOF.n bit and TOS.n bits are set. Communication is never
successful; that is, the frame was never transmitted (or received). An interrupt is asserted. Application
should handle this issue as desired and clear TOC.n bit which clears TOS.n bit which in turn clears the
MTOF.n bit.
2. Time-out condition occurs. Both MTOF.n bit and TOS.n bits are set. However, communication is
eventually successful; that is, the frame gets transmitted (or received). Both MTOF.n bit and TOS.n
bits are cleared automatically by the CPK. An interrupt is still asserted because the interrupt
occurrence was recorded in the PIE module. When the ISR scans the GIF register, it doesn't see the
MTOF0/1 bit set. This is the phantom interrupt scenario. This is handled per the application
requirements.
3. Time-out condition occurs. Both MTOF0/1 bit and TOS.n bits are set. While executing the ISR
pertaining to time-out, communication is successful. This situation must be handled carefully. The
application should not re-transmit a mailbox if the mailbox is sent between the time the interrupt is
asserted and the time the ISR is attempting to take corrective action. One way of doing this is to poll
the TM/RM bits in the CANES register. These bits indicate if the CPK is currently
transmitting/receiving. If that is the case, the application should wait till the communication is over and
then check the TOS.n bit again. If the communication is still not successful, then the application should
take the corrective action.
