www.ti.com
Registers
319
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Pulse Width Modulator (ePWM) Module
Figure 3-83. Trip-Zone Force Register (TZFRC)
15 8
Reserved
R-0
7 3 2 1 0
Reserved OST CBC Reserved
R-0 R/W-0 R/W-0 R- 0
LEGEND: R/W = Read/Write; R = Read only; -n = value after reset
Table 3-43. Trip-Zone Force Register (TZFRC) Field Descriptions
Bits Name Value Description
15- 3 Reserved Reserved
2 OST Force a One-Shot Trip Event via Software
0 Writing of 0 is ignored. Always reads back a 0.
1 Forces a one-shot trip event and sets the TZFLG[OST] bit.
1 CBC Force a Cycle-by-Cycle Trip Event via Software
0 Writing of 0 is ignored. Always reads back a 0.
1 Forces a cycle-by-cycle trip event and sets the TZFLG[CBC] bit.
0 Reserved Reserved
