www.ti.com Peripheral Interrupt Expansion (PIE)
151
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
System Control and Interrupts
Table 1-112. PIE Vector Table (continued)
Name
VECTOR
ID
(1)
Address
(2)
Size
(x16) Description
(3)
CPU
Priority
PIE Group
Priority
PIE Group 2 Vectors - MUXed into CPU INT2
INT2.1 40 0x0000 0D50 2 EPWM1_TZINT (ePWM1) 6 1 (highest)
INT2.2 41 0x0000 0D52 2 EPWM2_TZINT (ePWM2) 6 2
INT2.3 42 0x0000 0D54 2 EPWM3_TZINT (ePWM3) 6 3
INT2.4 43 0x0000 0D56 2 EPWM4_TZINT (ePWM4) 6 4
INT2.5 44 0x0000 0D58 2 EPWM5_TZINT (ePWM5) 6 5
INT2.6 45 0x0000 0D5A 2 EPWM6_TZINT (ePWM6) 6 6
INT2.7 46 0x0000 0D5C 2 Reserved - 6 7
INT2.8 47 0x0000 0D5E 2 Reserved - 6 8 (lowest)
PIE Group 3 Vectors - MUXed into CPU INT3
INT3.1 48 0x0000 0D60 2 EPWM1_INT (ePWM1) 7 1 (highest)
INT3.2 49 0x0000 0D62 2 EPWM2_INT (ePWM2) 7 2
INT3.3 50 0x0000 0D64 2 EPWM3_INT (ePWM3) 7 3
INT3.4 51 0x0000 0D66 2 EPWM4_INT (ePWM4) 7 4
INT3.5 52 0x0000 0D68 2 EPWM5_INT (ePWM5) 7 5
INT3.6 53 0x0000 0D6A 2 EPWM6_INT (ePWM6) 7 6
INT3.7 54 0x0000 0D6C 2 Reserved - 7 7
INT3.8 55 0x0000 0D6E 2 Reserved - 7 8 (lowest)
PIE Group 4 Vectors - MUXed into CPU INT4
INT4.1 56 0x0000 0D70 2 ECAP1_INT (eCAP1) 8 1 (highest)
INT4.2 57 0x0000 0D72 2 ECAP2_INT (eCAP2) 8 2
INT4.3 58 0x0000 0D74 2 ECAP3_INT (eCAP3) 8 3
INT4.4 59 0x0000 0D76 2 ECAP4_INT (eCAP4) 8 4
INT4.5 60 0x0000 0D78 2 ECAP5_INT (eCAP5) 8 5
INT4.6 61 0x0000 0D7A 2 ECAP6_INT (eCAP6) 8 6
INT4.7 62 0x0000 0D7C 2 Reserved - 8 7
INT4.8 63 0x0000 0D7E 2 Reserved - 8 8 (lowest)
PIE Group 5 Vectors - MUXed into CPU INT5
INT5.1 64 0x0000 0D80 2 EQEP1_INT (eQEP1) 9 1 (highest)
INT5.2 65 0x0000 0D82 2 EQEP2_INT (eQEP2) 9 2
INT5.3 66 0x0000 0D84 2 Reserved - 9 3
INT5.4 67 0x0000 0D86 2 Reserved - 9 4
INT5.5 68 0x0000 0D88 2 Reserved - 9 5
INT5.6 69 0x0000 0D8A 2 Reserved - 9 6
INT5.7 70 0x0000 0D8C 2 Reserved - 9 7
INT5.8 71 0x0000 0D8E 2 Reserved - 9 8 (lowest)
PIE Group 6 Vectors - MUXed into CPU INT6
INT6.1 72 0x0000 0D90 2 SPIRXINTA (SPI-A) 10 1 (highest)
INT6.2 73 0x0000 0D92 2 SPITXINTA (SPI-A) 10 2
INT6.3 74 0x0000 0D94 2 MRINTB (McBSP-B) 10 3
INT6.4 75 0x0000 0D96 2 MXINTB (McBSP-B) 10 4
INT6.5 76 0x0000 0D98 2 MRINTA (McBSP-A) 10 5
INT6.6 77 0x0000 0D9A 2 MXINTA (McBSP-A) 10 6
INT6.7 78 0x0000 0D9C 2 Reserved - 10 7
INT6.8 79 0x0000 0D9E 2 Reserved - 10 8 (lowest)
