Texas Instruments TMS320 2833 Series

(GPIO26 = 0)
Signal host that DSP is ready
Parallel_GetWordData16bit
Data
ready
(GPIO27 = 0)
?
No
Yes
GPIO[15:0]
Read word of data from
(GPIO26 = 1)
DSP ack read complete
Host
ack
(GPIO27 = 1)
?
Yes
No
Return WordData
www.ti.com Bootloader Features
195
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Boot ROM
Figure 2-22. 16-Bit Parallel GetWord Function
