Enhanced Pulse Width Modulator (ePWM) Module
3.2.7.2 Controlling and Monitoring the Trip-Zone Submodule
The trip-zone submodule operation is controlled and monitored through the following registers:
(1)
All trip-zone registers are EALLOW protected and can be modified only after executing the EALLOW instruction. For more
information, see the System Control and Interrupts chapter.
Table 3-18. Trip-Zone Submodule Registers
Register Name Address offset Shadowed Description
(1)
TZSEL 0x0012 No Trip-Zone Select Register
reserved 0x0013
TZCTL 0x0014 No Trip-Zone Control Register
TZEINT 0x0015 No Trip-Zone Enable Interrupt Register
TZFLG 0x0016 No Trip-Zone Flag Register
TZCLR 0x0017 No Trip-Zone Clear Register
TZFRC 0x0018 No Trip-Zone Force Register
3.2.7.3 Operational Highlights for the Trip-Zone Submodule
The following sections describe the operational highlights and configuration options for the trip-zone
submodule.
The trip-zone signals at pins TZ1 to TZ6 (also collectively referred to as TZn) are active low input signals.
When one of these pins goes low, it indicates that a trip event has occurred. Each ePWM module can be
individually configured to ignore or use each of the trip-zone pins . Which trip-zone pins are used by a
particular ePWM module is determined by the TZSEL register for that specific ePWM module. The trip-
zone signals may or may not be synchronized to the system clock (SYSCLKOUT) and digitally filtered
within the GPIO MUX block. A minimum 1 SYSCLKOUT low pulse on TZn inputs is sufficient to trigger a
fault condition in the ePWM module. The asynchronous trip makes sure that if clocks are missing for any
reason, the outputs can still be tripped by a valid event present on TZn inputs, providing the GPIO is
appropriately configured . For more information, see the GPIO section of the System Control and
Interrupts chapter.
Each TZn input can be individually configured to provide either a cycle-by-cycle or one-shot trip event for
an ePWM module. This configuration is determined by the TZSEL[CBCn], and TZSEL[OSHTn] control bits
(where n corresponds to the trip pin) respectively.
• Cycle-by-Cycle (CBC):
When a cycle-by-cycle trip event occurs, the action specified in the TZCTL register is carried out
immediately on the EPWMxA and/or EPWMxB output. Table 3-19 lists the possible actions. In addition,
the cycle-by-cycle trip event flag (TZFLG[CBC]) is set and a EPWMx_TZINT interrupt is generated if it
is enabled in the TZEINT register and PIE peripheral.
The specified condition on the pins is automatically cleared when the ePWM time-base counter
reaches zero (TBCTR = 0x0000) if the trip event is no longer present. Therefore, in this mode, the trip
event is cleared or reset every PWM cycle. The TZFLG[CBC] flag bit will remain set until it is manually
cleared by writing to the TZCLR[CBC] bit. If the cycle-by-cycle trip event is still present when the
TZFLG[CBC] bit is cleared, then it will again be immediately set.
• One-Shot (OSHT):
When a one-shot trip event occurs, the action specified in the TZCTL register is carried out
immediately on the EPWMxA and/or EPWMxB output. Table 3-19 lists the possible actions. In addition,
the one-shot trip event flag (TZFLG[OST]) is set and a EPWMx_TZINT interrupt is generated if it is
enabled in the TZEINT register and PIE peripheral. The one-shot trip condition must be cleared
manually by writing to the TZCLR[OST] bit.
The action taken when a trip event occurs can be configured individually for each of the ePWM output
pins by way of the TZCTL[TZA] and TZCTL[TZB] register bits fields. One of four possible actions, shown
in Table 3-19, can be taken on a trip event.
