Enhanced Quadrature Encoder Pulse (eQEP)
Table 6-17. QDECCTL Register Field Descriptions (continued)
Bit Field Type Reset Description
6 QIP R/W 0h
QEPI input polarity
Reset type: SYSRSn
0h (R/W) = No effect
1h (R/W) = Negates QEPI input
5 QSP R/W 0h
QEPS input polarity
Reset type: SYSRSn
0h (R/W) = No effect
1h (R/W) = Negates QEPS input
4-0 RESERVED R 0h
Reserved
