Enhanced Quadrature Encoder Pulse (eQEP)
Table 6-21. QEINT Register Field Descriptions (continued)
Bit Field Type Reset Description
3 QDC R/W 0h
Quadrature direction change interrupt enable
Reset type: SYSRSn
0h (R/W) = Interrupt is disabled
1h (R/W) = Interrupt is enabled
2 QPE R/W 0h
Quadrature phase error interrupt enable
Reset type: SYSRSn
0h (R/W) = Interrupt is disabled
1h (R/W) = Interrupt is enabled
1 PCE R/W 0h
Position counter error interrupt enable
Reset type: SYSRSn
0h (R/W) = Interrupt is disabled
1h (R/W) = Interrupt is enabled
0 RESERVED R 0h
Reserved
