Enhanced Quadrature Encoder Pulse (eQEP)
Table 6-22. QFLG Register Field Descriptions (continued)
Bit Field Type Reset Description
3 QDC R 0h
Quadrature direction change interrupt flag
Reset type: SYSRSn
0h (R/W) = No interrupt generated
1h (R/W) = Interrupt was generated
2 PHE R 0h
Quadrature phase error interrupt flag
Reset type: SYSRSn
0h (R/W) = No interrupt generated
1h (R/W) = Interrupt was generated
1 PCE R 0h
Position counter error interrupt flag
Reset type: SYSRSn
0h (R/W) = No interrupt generated
1h (R/W) = Interrupt was generated
0 INT R 0h
Global interrupt status flag
Reset type: SYSRSn
0h (R/W) = No interrupt generated
1h (R/W) = Interrupt was generated
