eQEP Registers
www.ti.com
438
SPRUI07–March 2020
Submit Documentation Feedback
Copyright © 2020, Texas Instruments Incorporated
Enhanced Quadrature Encoder Pulse (eQEP)
Table 6-24. QFRC Register Field Descriptions (continued)
Bit Field Type Reset Description
3 QDC R/W 0h
Force quadrature direction change interrupt
Reset type: SYSRSn
0h (R/W) = No effect
1h (R/W) = Force the interrupt
2 PHE R/W 0h
Force quadrature phase error interrupt
Reset type: SYSRSn
0h (R/W) = No effect
1h (R/W) = Force the interrupt
1 PCE R/W 0h
Force position counter error interrupt
Reset type: SYSRSn
0h (R/W) = No effect
1h (R/W) = Force the interrupt
0 RESERVED R 0h
Reserved
