External Interface (XINTF)
Table 14-13. XRDACTIVE
X2TIMING Read Active Period Waitstates
000 0 0
001 0 1 XTIMCLK cycle
1 2 XTIMCLK cycles
010 0 2 XTIMCLK cycles
1 4 XTIMCLK cycles
011 0 3 XTIMCLK cycles
1 6 XTIMCLK cycles
100 0 4 XTIMCLK cycles
1 8 XTIMCLK cycles
101 0 5 XTIMCLK cycles
1 10 XTIMCLK cycles
110 0 6 XTIMCLK cycles
1 12 XTIMCLK cycles
111 0 7 XTIMCLK cycles
1 14 XTIMCLK cycles (default)
Table 14-14. XRDTRAIL
X2TIMING Read Trail Period
00 0 0
01 0 1 XTIMCLK cycle
1 2 XTIMCLK cycles
10 0 2 XTIMCLK cycles
1 4 XTIMCLK cycles
11 0 3 XTIMCLK cycles
1 6 XTIMCLK cycles (default)
Table 14-15. XWRLEAD
X2TIMING Write Lead Period
00 0 0
01 0 1 XTIMCLK cycle
1 2 XTIMCLK cycles
10 0 2 XTIMCLK cycles
1 4 XTIMCLK cycles
11 0 3 XTIMCLK cycles
1 6 XTIMCLK cycles (default)
Table 14-16. XWRACTIVE
X2TIMING Write Active Period Waitstates
000 0 0
001 0 1 XTIMCLK cycle
1 2 XTIMCLK cycles
010 0 2 XTIMCLK cycles
1 4 XTIMCLK cycles
011 0 3 XTIMCLK cycles
1 6 XTIMCLK cycles
