Embedded NVM (eNVM) Controllers
UG0331 User Guide Revision 15.0 177
Table 105 • SW_ENVMREMAPSIZE
Bit 4 Bit 3 Bit 2 Bit 1 Bit 0 Remap Size
0 0 0 0 0 Reserved
0 0 0 0 1 Reserved
0 0 0 1 0 Reserved
0 0 0 1 1 Reserved
0 0 1 0 0 Reserved
0 0 1 0 1 Reserved
0 0 1 1 0 Reserved
0 0 1 1 1 Reserved
0 1 0 0 0 Reserved
0 1 0 0 1 Reserved
0 1 0 1 0 Reserved
0 1 0 1 1 Reserved
0 1 1 0 0 Reserved
0110116 KB
0111032 KB
0111164 KB
10000128 KB
10001256 KB
1 0 0 1 0 512 KB, reset value
Table 106 • ENVM_REMAP_BASE_CR
Bit
Number Name
Reset
Value Description
[31:19] Reserved 0 Reserved.
[18:1] SW_ENVMREMAPBASE 0 Offset address of eNVM for remapping.
SW_ENVMREMAPBASE indicates the offset within eNVM
address space of the base address of the segment in eNVM,
which is to be remapped to location 0x00000000.
Bit 0 of this register is defined as SW_ENVMREMAPENABLE
and must be set to get the remapping done with new addresses
filled in this register.
0 SW_ENVMREMAPENABLE 0 0: eNVM remap not enabled. Bottom of eNVM is mapped to
address 0x00000000.
1: eNVM remap enabled. eNVM visible at 0x00000000 is a
remapped segment of the eNVM.
