Microsemi SmartFusion2 - Table 549 IOMUX CELL 14

MSS GPIO
UG0331 User Guide Revision 15.0 580
16.4.7.4 IOMUX CELL 14
I/O pad name: CAN_RXBUS_USBA_DATA1_MGPIO3A
16.4.7.5 IOMUX CELL 15
I/O pad name: CAN_ TX_EBL_USBA_DATA2_MGPIO4A
16.4.7.6 IOMUX CELL 16
I/O pad name: SPI0_SDI_USBA_DIR_MGPIO5A
Table 549 • IOMUX CELL 14
I/O Pad Ports
IOMUXCELL Interface
CAN USB Controller GPIO[3] FPGA Fabric
IN CAN_RX_BUS USBA_DATAI[1] GPIOA_IN[3] IN_A F2H_GPIN[14]
OUT GND DATAO[1] GPIO_OUT[3] IN_B F2H_SCP[14]
OE GND ~NDATAOE GPIO_OE[3] OUT_A H2F_A[14]
OUT_B H2F_B[14]
Table 550 • IOMUX CELL 15
I/O Pad Ports
IOMUXCELL Interface
CAN USB Controller GPIO[4] FPGA Fabric
IN NC USBA_DATAI[2] GPIOA_IN[4] IN_A F2H_GPIN[15]
OUT CAN_TB_EBL_n DATAO[2] GPIO_OUT[4] IN_B F2H_SCP[15]
OE VDD ~NDATAOE GPIO_OE[4] OUT_A H2F_A[15]
OUT_B H2F_B[15]
Table 551 • IOMUX CELL 16
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[5] FPGA Fabric
IN SPISDI_0_IN USBA_DIR GPIOA_IN[5] IN_A F2H_GPIN[16]
OUT GND GND GPIO_OUT[5] IN_B F2H_SCP[16]
OE GND GND GPIO_OE[5] OUT_A H2F_A[16]
OUT_B H2F_B[16]
