Microsemi SmartFusion2 - Figure 103 Block Diagram of APB Destinations Connected to AHB Bus Matrix

AHB Bus Matrix
UG0331 User Guide Revision 15.0 213
The following figure shows the block diagram of all the APB peripherals connected to AHB bus matrix
using the AHB-to-AHB bridge. The MSS APB peripherals are connected through the AHB to APB bus.
Figure 103 • Block Diagram of APB Destinations Connected to AHB Bus Matrix
AHB BUS
AHB Bus Matrix
10X7
MS5
AHB to AHB bridge with Address decoder
MS_APB0
MS_APB1 MS_APB2
AHB to APB_0
AHB to APB_1
AHB to APB_2
MMUART0
MMUART1
SPI_0
SPI_1
I2C_0
I2C_1
DMA
CAN
WATCHDOG
GPIO
RTC
APB Config bus
for MDDR, FDDR,
PCIe etc
