Microsemi SmartFusion2 - Table 401 TBYT; Table 403 TMCA

Ethernet MAC
UG0331 User Guide Revision 15.0 421
Table 401 • TBYT
Bit Number Name Reset Value Description
[31:24] Reserved 0x0 Reserved
[23:0] TPKT 0x0 Transmit byte counter: Incremented by the number of bytes that
are transmitted including fragments of frames, which are involved
in collisions. This count does not include preamble/SFD or jam
bytes.
Table 402 • TPKT
Bit Number Name Reset Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TPKT 0x0 Transmit packet counter: Incremented for each transmitted packet
(including bad packets, excessive deferred packets, excessive
collision packets, late collision packets, all unicast, broadcast, and
multicast packets).
Table 403 • TMCA
Bit Number Name Reset Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TPKT 0x0 Transmit packet counter: Incremented for each transmitted packet
(including bad packets, excessive deferred packets, excessive
collision packets, late collision packets, all unicast, broadcast, and
multicast packets).
Table 404 • TBCA
Bit Number Name Reset Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TBCA 0x0 Transmit broadcast packet counter: Incremented for each
broadcast frame transmitted (excluding multicast frames).
Table 405 • TXPF
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TXPF 0x0 Transmit PAUSE frame packet counter: Incremented each time a
valid PAUSE MAC Control frame is transmitted.
