Watchdog Timer
UG0331 User Guide Revision 15.0 641
20.5 SYSREG Control Registers
In addition to the specific watchdog timer registers mentioned in Table 635, page 638, the registers
mentioned in the following table also control the behavior of the watchdog timer. These registers are
located in the System Register Block and are listed here for clarity. Refer to the SYSREG section of
System Register Block, page 670 for a detailed description of each register and bit.
Note: Register Types RW-P, RO-P are explained in System Register Block, page 670.
Table 644 • Watchdog Timer SYSREG
Register
Name
Register
Type
Flash Write
Protect
Reset
Source Description
WDOG_CR RW-P Register Poreset_n Bit 0 of this register is WDOGENABLE.This goes as the Enable
bit for the watchdog timer module. The status of this bit can be
monitored in the WDOGENABLE register.
Bit 1of this register is WDOGMODE. This bit is Reset/Interrupt
mode selection bit from the system register. This value can be
read from the WDOGCONTROL register within the watchdog
timer module.
WDOGLOAD RO-P Poreset_n Bits [25:0] of this register contain the upper 26-bits of the
WDOGLOAD value register.
WDOGMVRP RO-P Poreset_n This register contains the WDOGMVRP value.
