Ethernet MAC
UG0331 User Guide Revision 15.0 423
Table 412 • TNCL
Bit Number Name Reset Value Description
[31:13] Reserved 0x0 Reserved
[12:0] TNCL 0X0 Transmit total collision counter:
Incremented by the number of collisions experienced during the
transmission of a frame due to simultaneous transmitting and
receiving.
Table 413 • TPFH
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TPFH 0x0 Transmit PAUSE frames honored counter: Incremented each time a
valid PAUSE MAC control frame is transmitted and honored.
Table 414 • TDRP
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TDRP 0x0 Transmit drop frame counter: Incremented each time the transmit
PAUSE frame honored input to PE-MSTAT is asserted.
Table 415 • TJBR
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TJBR 0x0 Transmit jabber frame counter: Incremented for each oversized
transmitted frame with an incorrect FCS value.
Table 416 • TFCS
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TFCS 0x0 Transmit FCS error counter: incremented for each valid sized packet
with an incorrect FCS value.
Table 417 • TXCF
Bit Number Name Reset Value Description
[31:12] Reserved 0x0 Reserved
[11:0] TXCS 0x0 Transmit control frame counter: incremented for each valid size
frame with a type field signifying a control frame.
