MSS GPIO
UG0331 User Guide Revision 15.0 589
16.4.7.37 IOMUX CELL 47
I/O pad name: MMUART0_CTS_USBC_DATA7__MGPIO19B
16.4.7.38 IOMUX CELL 48
I/O pad name: MMUART0_DSR_ MGPIO20B
16.4.7.39 IOMUX CELL 49
I/O pad name: MMUART0_RI_ MGPIO21B
16.4.7.40 IOMUX CELL 50
I/O pad name: MMUART0_DCD_ MGPIO22B
Table 582 • IOMUX CELL 47
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[19] FPGA Fabric
IN CTS_0_IN USBC_DATAI[7] GPIOB_IN[19] IN_A F2H_GPIN[47]
OUT GND DATAO[7] GPIO_OUT[19] IN_B F2H_SCP[47]
OE GND ~NDATAOE GPIO_OE[19] OUT_A H2F_A[47]
OUT_B H2F_B[47]
Table 583 • IOMUX CELL 48
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[20] FPGA Fabric
IN DSR_0_IN NC GPIOB_IN[20] IN_A F2H_GPIN[48]
OUT GND GND GPIO_OUT[20] IN_B F2H_SCP[48]
OE GND GND GPIO_OE[20] OUT_A H2F_A[48]
OUT_B H2F_B[48]
Table 584 • IOMUX CELL 49
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[21] FPGA Fabric
IN RI_0_IN NC GPIOB_IN[21] IN_A F2H_GPIN[49]
OUT GND GND GPIO_OUT[21] IN_B F2H_SCP[49]
OE GND GND GPIO_OE[21] OUT_A H2F_A[49]
OUT_B H2F_B[49]
Table 585 • IOMUX CELL 50
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[22] FPGA Fabric
IN DCD_0_IN NC GPIOB_IN[22] IN_A F2H_GPIN[50]
OUT GND GND GPIO_OUT[22] IN_B F2H_SCP[50]
OE GND GND GPIO_OE[22] OUT_A H2F_A[50]
OUT_B H2F_B[50]
