Microsemi SmartFusion2 - Table 578 IOMUX CELL 43

MSS GPIO
UG0331 User Guide Revision 15.0 588
16.4.7.33 IOMUX CELL 43
I/O pad name: MMUART1_SCK_USBC_DATA4__MGPIO25B
16.4.7.34 IOMUX CELL 44
I/O pad name: MMUART1_RXD_USBC_DATA3__MGPIO26B
16.4.7.35 IOMUX CELL 45
I/O pad name: MMUART0_RTS_USBC_DATA5__MGPIO17B
16.4.7.36 IOMUX CELL 46
I/O pad name: MMUART0_DTR_USBC_DATA6__MGPIO18B
Table 578 • IOMUX CELL 43
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[25] FPGA Fabric
IN MMUART1_SCK_IN USBC_DATAI[4] GPIOB_IN[25] IN_A F2H_GPIN[43]
OUT MMUART1_BAUDOUTN DATAO[4] GPIO_OUT[25] IN_B F2H_SCP[43]
OE MMUART1_E_MST_SCK ~NDATAOE GPIO_OE[25] OUT_A H2F_A[43]
OUT_B H2F_B[43]
Table 579 • IOMUX CELL 44
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[26] FPGA Fabric
IN RXD_1 _IN USBC_DATAI[3] GPIOB_IN[26] IN_A F2H_GPIN[44]
OUT GND DATAO[3] GPIO_OUT[26] IN_B F2H_SCP[44]
OE GND ~NDATAOE GPIO_OE[26] OUT_A H2F_A[44]
OUT_B H2F_B[44]
Table 580 • IOMUX CELL 45
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[17] FPGA Fabric
IN NC USBC_DATAI[5] GPIOB_IN[17] IN_A F2H_GPIN[45]
OUT RTS_0OUT DTAO[5] GPIO_OUT[17] IN_B F2H_SCP[45]
OE VDD ~NDATAOE GPIO_OE[17] OUT_A H2F_A[45]
OUT_B H2F_B[45]
Table 581 • IOMUX CELL 46
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[18] FPGA Fabric
IN NC USBC_DATAI[6] GPIOB_IN[18] IN_A F2H_GPIN[46]
OUT DTR_0_OUT DATAO[6] GPIO_OUT[18] IN_B F2H_SCP[46]
OE VDD ~NDATAOE GPIO_OE[18] OUT_A H2F_A[46]
OUT_B H2F_B[46]
