Cortex-M3 Processor (Reference Material)
UG0331 User Guide Revision 15.0 76
3.6.6 Multiply and Divide Instructions
The following table shows the multiply and divide instructions:
3.6.6.1 MUL, MLA, and MLS
Multiply, Multiply with Accumulate, and Multiply with Subtract, using 32-bit operands, and producing a
32-bit result.
3.6.6.1.1 Syntax
MUL{S}{cond} {Rd,} Rn, Rm ; Multiply
MLA{cond} Rd, Rn, Rm, Ra ; Multiply with accumulate
MLS{cond} Rd, Rn, Rm, Ra ; Multiply with subtract
where:
cond is an optional condition code, see Conditional Execution, page 55.
S is an optional suffix. If
S
is specified, the condition code flags are updated on the result of the operation,
see Conditional Execution, page 55.
Rd is the destination register. If
Rd
is omitted, the destination register is
Rn
.
Rn, Rm are registers holding the values to be multiplied.
Ra is a register holding the value to be added or subtracted from.
3.6.6.1.2 Operation
The
MUL
instruction multiplies the values from
Rn
and
Rm
, and places the least significant 32 bits of the
result in
Rd
.
The
MLA
instruction multiplies the values from
Rn
and
Rm
, adds the value from
Ra
, and places the least
significant 32 bits of the result in
Rd
.
The
MLS
instruction multiplies the values from
Rn
and
Rm
, subtracts the product from the value from
Ra
,
and places the least significant 32 bits of the result in
Rd
.
The results of these instructions do not depend on whether the operands are signed or unsigned.
Table 34 • Multiply and Divide Instructions
Mnemonic Brief Description See
MLA Multiply with Accumulate, 32-bit result "MUL, MLA, and MLS" on page 71
MLS Multiply and Subtract, 32-bit result "MUL, MLA, and MLS" on page 71
MUL Multiply, 32-bit result "MUL, MLA, and MLS" on page 71
SDIV Signed Divide "SDIV and UDIV" on page 73
SMLAL Signed Multiply with Accumulate
(32x32+64), 64-bit result
"UMULL, UMLAL, SMULL, and SMLAL" on page 72
SMULL Signed Multiply (32x32), 64-bit result "UMULL, UMLAL, SMULL, and SMLAL" on page 72
UDIV Unsigned Divide "SDIV and UDIV" on page 73
UMLAL Unsigned Multiply with Accumulate
(32x32+64), 64-bit result
"UMULL, UMLAL, SMULL, and SMLAL" on page 72
UMULL Unsigned Multiply (32x32), 64-bit result "UMULL, UMLAL, SMULL, and SMLAL" on page 72
