Microsemi SmartFusion2 - Table 380 TR511

Ethernet MAC
UG0331 User Guide Revision 15.0 417
Table 380 • TR511
Bit Number Name
Reset
Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TR511 0x0 Transmit and receive 256 to 511 byte frame counter: Incremented for each good
or bad, transmitted and received frame, which is 256 to 511 bytes in length
inclusive (excluding framing bits but including FCS bytes).
Table 381 • TR1K
Bit Number Name
Reset
Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TR1K 0x0 Transmit and receive 512 to 1023 byte frame counter: Incremented for each
good or bad, transmitted and received frame, which is 512 to 1023 bytes in
length inclusive (excluding framing bits but including FCS bytes).
Table 382 • TRMAX
Bit Number Name Reset Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TRMAX 0x0 Transmit and receive 1024 to 1518 byte frame counter:
Incremented for each good or bad, transmitted and received
frame, which is 1024 to 1518 bytes in length inclusive (excluding
framing bits but including FCS bytes).
Table 383 • TRMGV
Bit Number Name Reset Value Description
[31:18] Reserved 0x0 Reserved
[17:0] TRMGV 0x0 Transmit and receive 1519 to 1522 byte VLAN frame counter:
Incremented for each good virtual local area network (VLAN)
transmitted and received frame which is 1519 to 1522 bytes in
length inclusive (excluding framing bits but including FCS bytes).
Table 384 • RBYT
Bit Number Name Reset Value Description
[31:24] Reserved 0x0 Reserved
[23:0] RBYT 0x0 Receive byte frame counter: The statistic counter register is
incremented by the byte count of all the frames received, including
those in the bad packets, excluding framing bits but including FCS
bytes.
