System Register Block
UG0331 User Guide Revision 15.0 715
22.3.59 eSRAM0 EDAC Count
22.3.60 eSRAM1 EDAC Count
22.3.61 MAC EDAC Transmitter Count
22.3.62 MAC EDAC Receiver Count
Table 716 • ESRAM0_EDAC_CNT
Bit
Number Name
Reset
Value Description
[31:16] ESRAM0_EDAC_CNT_2E 0 16-bit counter value in eSRAM0 incremented by eSRAM0
EDAC 2-bit error. The counter will not roll back and will stay at
its maximum value.
[15:0] ESRAM0_EDAC_CNT_1E 0 I16-bit counter value in eSRAM0 incremented by eSRAM0
EDAC 1-bit error. The counter will not roll back and will stay at
its maximum value.
Table 717 • ESRAM1_EDAC_CNT
Bit
Number Name
Reset
Value Description
[31:16] ESRAM1_EDAC_CNT_2E 0 16-bit counter value in eSRAM1 incremented by eSRAM1
EDAC 2-bit error. The counter will not roll back and will stay at
its maximum value.
[15:0] ESRAM1_EDAC_CNT_1E 0 16-bit counter value in eSRAM1 incremented by eSRAM1
EDAC 1-bit error. The counter will not roll back and will stay at
its maximum value.
Table 718 • MAC_EDAC_TX_CNT
Bit
Number Name
Reset
Value Description
[31:16] MAC_EDAC_TX_CNT_2E 0 16-bit counter that counts the number of 2-bit errors for
Ethernet (MAC TX EDAC). The counter will not roll back and
will stay at its maximum value.
[15:0] MAC_EDAC_TX_CNT_1E 0 16-bit counter that counts the number of 1-bit errors for
Ethernet (MAC TX EDAC). The counter will not roll back and
will stay at its maximum value.
Table 719 • MAC_EDAC_RX_CNT
Bit
Number Name
Reset
Value Description
[31:16] MAC_EDAC_RX_CNT_2E 0 16-bit counter that counts the number of 2-bit errors for
Ethernet (MAC RX EDAC). The counter will not roll back and
will stay at its maximum value.
[15:0] MAC_EDAC_RX_CNT_1E 0 16-bit counter that counts the number of 1-bit errors for
Ethernet (MAC RX EDAC). The counter will not roll back and
will stay at its maximum value.
