Fabric Interface Controller
UG0331 User Guide Revision 15.0 764
The following diagram shows the AHB-Lite bus signals from the fabric interface controller to the fabric
slave for write transaction in Synchronous Pipelined mode.
Figure 331 • AHB-Lite Bus Signals from FIC to the Fabric Slave for a Write Transaction in Synchronous
Pipelined Mode
The following diagram shows the AHB-Lite bus signals from the fabric interface controller to the fabric
slave for read transaction in Synchronous Pipelined mode.
Figure 332 • AHB-Lite Bus Signals from FIC to the Fabric Slave for a Read Transaction in Synchronous
Pipelined Mode
T1 T2 T3 T4 T5 T6 T7
T8
A
A + 4
00
00
00
00
10
10
10
10
FIC_X_AHB_M_HCLK
FIC_X_AHB_M_
HADDR[31:0]
FIC_X_AHB_M_HTRANS
FIC_X_AHB_M_HSIZE
FIC_X_AHB_M_HWRITE
FIC_X_AHB_M_HSEL
FIC_X_AHB_M_HWDATA[31:0]
FIC_X_AHB_M_HREADY
Data (A)
Data (A+4)
FIC_X_AHB_M_HCLK
FIC_X_AHB_M_
HADDR[31:0]
FIC_X_AHB_M_HTRANS
FIC_X_AHB_M_HSIZE
FIC_X_AHB_M_HWRITE
FIC_X_AHB_M_HSEL
FIC_X_AHB_M_HRDATA[31:0]
FIC_X_AHB_M_HREADY
T1 T2 T3 T4 T5 T6 T7
T8
A
A + 4
00
00
00
00
10
10
10
10
Data (A)
