MSS GPIO
UG0331 User Guide Revision 15.0 582
16.4.7.10 IOMUX CELL 20
I/O pad name: SPI0_SS2_USBA_DATA6_MGPIO9A
16.4.7.11 IOMUX CELL 21
I/O pad name: SPI0_SS3_USBA_DATA7_MGPIO10A
16.4.7.12 IOMUX CELL 22
I/O pad name: SPI0_SS4_MGPIO19A
16.4.7.13 IOMUX CELL 23
I/O pad name: SPI0_SS5_MGPIO20A
Table 555 • IOMUX CELL 20
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[9] FPGA Fabric
IN NC USBA_DATAI[6] GPIOA_IN[9] IN_A F2H_GPIN[20]
OUT SPISS_0_OUT[2] DATAO[6] GPIO_OUT[9] IN_B F2H_SCP[20]
OE SPI_0_MASTER ~NDATAOE GPIO_OE[9] OUT_A H2F_A[20]
OUT_B H2F_B[20]
Table 556 • IOMUX CELL 21
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[10] FPGA Fabric
IN NC USBA_DATAI[7] GPIOA_IN[10] IN_A F2H_GPIN[21]
OUT SPISS_0_OUT[3] DATAO[7] GPIO_OUT[10] IN_B F2H_SCP[21]
OE SPI_0_MASTER ~NDATAOE GPIO_OE[10] OUT_A H2F_A[21]
OUT_B H2F_B[21]
Table 557 • IOMUX CELL 22
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[19] FPGA Fabric
IN NC NC GPIOA_IN[19] IN_A GND
OUT SPISS_0_OUT[4] GND GPIO_OUT[19] IN_B GND
OE SPI_0_MASTER GND GPIO_OE[19] OUT_A H2F_A[22]
OUT_B NC
Table 558 • IOMUX CELL 23
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[20] FPGA Fabric
IN NC NC GPIOA_IN[20] IN_A GND
OUT SPISS_0_OUT[5] GND GPIO_OUT[20] IN_B GND
OE SPI_0_MASTER GND GPIO_OE[20] OUT_A H2F_A[23]
OUT_B NC
