MSS GPIO
UG0331 User Guide Revision 15.0 566
16.2.2 MSS GPIO Reset Functionality
The MSS GPIO outputs can be reset to a predefined state (logic 1 or logic 0) either by the soft resets
coming from the SYSREG block or the power-on reset or the user reset signal (MSS_GPIO_RESET_N)
from the FPGA fabric. The selection of the reset can be done through the MSS Configurator in Libero
SoC or by writing to reset select registers of the SYSREG block. Refer to Table 544, page 578 for reset
select signals.
Table 536 • MSS GPIO Interrupts
Cortex-M3
Processor Interrupt Signal Source Description
INTISR[50] GPIO_INT[0] GPIO_0 Interrupt from GPIO_0
INTISR[51] GPIO_INT[1] GPIO_1 Interrupt from GPIO_1
INTISR[52] GPIO_INT[2] GPIO_2 Interrupt from GPIO_2
INTISR[53] GPIO_INT[3] GPIO_3 Interrupt from GPIO_3
INTISR[54] GPIO_INT[4] GPIO_4 Interrupt from GPIO_4
INTISR[55] GPIO_INT[5] GPIO_5 Interrupt from GPIO_5
INTISR[56] GPIO_INT[6] GPIO_6 Interrupt from GPIO_6
INTISR[57] GPIO_INT[7] GPIO_7 Interrupt from GPIO_7
INTISR[58] GPIO_INT[8] GPIO_8 Interrupt from GPIO_8
INTISR[59] GPIO_INT[9] GPIO_9 Interrupt from GPIO_9
INTISR[60] GPIO_INT[10] GPIO_10 Interrupt from GPIO_10
INTISR[61] GPIO_INT[11] GPIO_11 Interrupt from GPIO_11
INTISR[62] GPIO_INT[12] GPIO_12 Interrupt from GPIO_12
INTISR[63] GPIO_INT[13] GPIO_13 Interrupt from GPIO_13
INTISR[64] GPIO_INT[14] GPIO_14 Interrupt from GPIO_14
INTISR[65] GPIO_INT[15] GPIO_15 Interrupt from GPIO_15
INTISR[66] GPIO_INT[16] GPIO_16 Interrupt from GPIO_16
INTISR[67] GPIO_INT[17] GPIO_17 Interrupt from GPIO_17
INTISR[68] GPIO_INT[18] GPIO_18 Interrupt from GPIO_18
INTISR[69] GPIO_INT[19] GPIO_19 Interrupt from GPIO_19
INTISR[70] GPIO_INT[20] GPIO_20 Interrupt from GPIO_20
INTISR[71] GPIO_INT[21] GPIO_21 Interrupt from GPIO_21
INTISR[72] GPIO_INT[22] GPIO_22 Interrupt from GPIO_22
INTISR[73] GPIO_INT[23] GPIO_23 Interrupt from GPIO_23
INTISR[74] GPIO_INT[24] GPIO_24 Interrupt from GPIO_24
INTISR[75] GPIO_INT[25] GPIO_25 Interrupt from GPIO_25
INTISR[76] GPIO_INT[26] GPIO_26 Interrupt from GPIO_26
INTISR[77] GPIO_INT[27] GPIO_27 Interrupt from GPIO_27
INTISR[78] GPIO_INT[28] GPIO_28 Interrupt from GPIO_28
INTISR[79] GPIO_INT[29] GPIO_29 Interrupt from GPIO_29
INTISR[80] GPIO_INT[30] GPIO_30 Interrupt from GPIO_30
INTISR[81] GPIO_INT[31] GPIO_31 Interrupt from GPIO_31
