Microsemi SmartFusion2 - Table 570 IOMUX CELL 35

MSS GPIO
UG0331 User Guide Revision 15.0 586
16.4.7.25 IOMUX CELL 35
I/O pad name: SPI1_SS7_MGPIO24A
16.4.7.26 IOMUX CELL 36
I/O pad name: MMUART1_RTS_MGPIO11B
16.4.7.27 IOMUX CELL 37
I/O pad name: MMUART1_DTR_MGPIO12B
16.4.7.28 IOMUX CELL 38
I/O pad name: MMUART1_CTS_MGPIO13B
Table 570 • IOMUX CELL 35
I/O Pad Ports
IOMUXCELL Interface
SPI_1 USB Controller GPIO[24] FPGA Fabric
IN NC NC GPIOA_IN[24] IN_A GND
OUT SPISS_1_OUT[7] GND GPIO_OUT[24] IN_B GND
OE SPI_1_MASTER GND GPIO_OE[24] OUT_A H2F_A[35]
OUT_B NC
Table 571 • IOMUX CELL 36
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[11] FPGA Fabric
IN NC NC GPIOB_IN[11] IN_A F2H_GPIN[36]
OUT RTS_1_OUT GND GPIO_OUT[11] IN_B F2H_SCP[36]
OE VDD GND GPIO_OE[11] OUT_A H2F_A[36]
OUT_B H2F_B[36]
Table 572 • IOMUX CELL 37
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[12] FPGA Fabric
IN NC NC GPIOB_IN[12] IN_A GND
OUT DTR_1_OUT GND GPIO_OUT[12] IN_B GND
OE VDD GND GPIO_OE[12] OUT_A H2F_A[37]
OUT_B NC
Table 573 • IOMUX CELL 38
I/O Pad Ports
IOMUXCELL Interface
MMUART_1 USB Controller GPIO[13] FPGA Fabric
IN CTS_1_IN NC GPIOB_IN[13] IN_A GND
OUT GND GND GPIO_OUT[13] IN_B GND
OE VDD GND GPIO_OE[13] OUT_A H2F_A[38]
OUT_B NC
