16.4.7.17 IOMUX CELL 27
I/O pad name: SPI1_SDO_MGPIO12A
16.4.7.18 IOMUX CELL 28
I/O pad name: SPI1_SS0_MGPIO13A
16.4.7.19 IOMUX CELL 29
I/O pad name: SPI1_SS1_MGPIO14A
16.4.7.20 IOMUX CELL 30
I/O pad name: SPI1_SS2_MGPIO15A
Table 562 • IOMUX CELL 27
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[12] FPGA Fabric
IN NC NC GPIOA_IN[12] IN_A F2H_GPIN[27]
OUT SPISDO_1_OUT GND GPIO_OUT[12] IN_B F2H_SCP[27]
OE SPIOEN_0 GND GPIO_OE[12] OUT_A H2F_A[27]
OUT_B H2F_B[27]
Table 563 • IOMUX CELL 28
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[13] FPGA Fabric
IN SPISSI_1_IN NC GPIOA_IN[13] IN_A F2H_GPIN[28]
OUT SPISS_1_OUT[0] GND GPIO_OUT[13] IN_B F2H_SCP[28]
OE SPI_1_MASTER GND GPIO_OE[13] OUT_A H2F_A[28]
OUT_B H2F_B[28]
Table 564 • IOMUX CELL 29
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[14] FPGA Fabric
IN NC NC GPIOA_IN[14] IN_A F2H_GPIN[29]
OUT SPISS_1_OUT[1] GND GPIO_OUT[14] IN_B F2H_SCP[29]
OE SPI_1_MASTER GND GPIO_OE[14] OUT_A H2F_A[29]
OUT_B H2F_B[29]
Table 565 • IOMUX CELL 30
I/O Pad Ports
IOMUXCELL Interface
SPI_0 USB Controller GPIO[15] FPGA Fabric
IN NC NC GPIOA_IN[15] IN_A F2H_GPIN[30]
OUT SPISS_1_OUT[2] GND GPIO_OUT[15] IN_B F2H_SCP[30]
OE SPI_1_MASTER GND GPIO_OE[15] OUT_A H2F_A[30]
OUT_B H2F_B[30]
