Microsemi SmartFusion2 - Table 590 IOMUX CELL 55

MSS GPIO
UG0331 User Guide Revision 15.0 591
16.4.7.45 IOMUX CELL 55
I/O pad name: I2C0_SCL_ USBC_DATA1_MGPIO31B
16.4.7.46 IOMUX CELL 56
I/O pad name: USBD_DATA7_MGPIO23B
Table 590 • IOMUX CELL 55
I/O Pad Ports
IOMUXCELL Interface
I2C_0 USB Controller GPIO[31] FPGA Fabric
IN SCL_0_IN USBC_DATAI[1] GPIOB_IN[31] IN_A F2H_GPIN[55]
OUT GND DATAO[1] GPIO_OUT[31] IN_B F2H_SCP[55]
OE ~SCL_0_OUT ~NDATAOE GPIO_OE[31] OUT_A H2F_A[55]
OUT_B H2F_B[55]
Table 591 • IOMUX CELL 56
I/O Pad Signals
IOMUXCELL Interface
I2C_0 USB Controller GPIO[23] FPGA Fabric
IN NC USBD_DATAI[7] GPIOB_IN[23] IN_A GND
OUT GND DATAO[7] GPIO_OUT[23] IN_B GND
OE GND ~NDATAOE GPIO_OE[23] OUT_A NC
OUT_B NC
