System Register Block
UG0331 User Guide Revision 15.0 687
Bits [18:N] of this bus indicate the base address of the remapped segment. The value of N depends on
the eNVM remap section size, so that the base address is aligned according to an even multiple of the
segment size. The power of 2 size specified by SW_ENVMREMAPSIZE[4:0] (Table 657, page 686)
defines how many bits of the base address are used. For example, if the SW_ENVMREMAPSIZE[4:0] is
01111, this corresponds to a segment size of 64 KB. 64 KB is 2 to the power of 16. Therefore the value of
N in this case, is 16. So the base address of the region, in this case, is specified by
SW_ENVMREMAPSIZE[18:16].
This register should only be written by Cortex-M3 processor firmware using 32-bit accesses. The
behavior of the system is undefined if other size accesses are used.
22.3.7 eNVM FPGA Fabric Remap Base Address Register
Bits [18:N] of this bus indicate the base address of the remapped segment. The value of N depends on
the eNVM remap section size, so that the base address is aligned according to an even multiple of
segment size. The power of 2 size specified by SW_ENVMREMAPSIZE[4:0] (Table 657, page 686)
defines how many bits of base address are used. For example, if the SW_ENVMREMAPSIZE[4:0] is
01111, this corresponds to a segment size of 64KB. 64KB is 2 to the power of 16. Therefore the value of
N in this case, is 16. So the base address of the region, in this case, is specified by
SW_ENVMREMAPSIZE[18:16].
This register should only be written by Cortex-M3 processor firmware using 32-bit accesses. The
behavior of the system is undefined if other size accesses are used.
22.3.8 Cache Configuration Register
Table 659 • ENVM_REMAP_FAB_CR
Bit
Number Name
Reset
Value Description
[31:19] Reserved 0
[18:1] SW_ENVMFABREMAPBASE 0 Offset within eNVM address space of the base address of
the segment in eNVM, which is to be remapped to location
0x00000000 for use by a soft processor in the FPGA
fabric.
0 SW_ENVMFABREMAPENABLE 0 0: eNVM fabric remap not enabled for accesses by fabric
master. The portion of eNVM visible in the eNVM window
at location 0x00000000 of a soft processor’s memory
space corresponds to the memory locations at the bottom
of eNVM.
1: eNVM fabric remap enabled. The portion of eNVM
visible at location 0x00000000 of a soft processor’s
memory space of is a remapped segment of eNVM.
Table 660 • CC_CR
Bit
Number Name
Reset
Value Description
[31:3] Reserved 0
2 CC_CACHE_LOCK 0 Allows the cache lock to be enabled. The allowed values:
0: Disabled
1: Enabled
1 CC_SBUS_WR_MODE 0 Allows debug mode SBUS writes to cache memory to be enabled.
The allowed values:
0: Disabled
1: Enabled
