Microsemi SmartFusion2 - Table 586 IOMUX CELL 51

MSS GPIO
UG0331 User Guide Revision 15.0 590
16.4.7.41 IOMUX CELL 51
I/O pad name: MMUART0_TXD_ USBC_DIR_MGPIO27B
16.4.7.42 IOMUX CELL 52
I/O pad name: MMUART0_RXD_ USBC_STP_MGPIO28B
16.4.7.43 IOMUX CELL 53
I/O pad name: MMUART0_SCK_ USBC_NXT_MGPIO29B
16.4.7.44 IOMUX CELL 54
I/O pad name: I2C0_SDA_ USBC_DATA0_MGPIO30B
Table 586 • IOMUX CELL 51
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[27] FPGA Fabric
IN TXD_0_IN USBC_DIR GPIOB_IN[27] IN_A F2H_GPIN[51]
OUT TXD_0_OUT GND GPIO_OUT[27] IN_B F2H_SCP[51]
OE MMUART0_TE GND GPIO_OE[27] OUT_A H2F_A[51]
OUT_B H2F_B[51]
Table 587 • IOMUX CELL 52
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[28] FPGA Fabric
IN RXD_0_IN NC GPIOB_IN[28] IN_A F2H_GPIN[52]
OUT GND STP GPIO_OUT[28] IN_B F2H_SCP[52]
OE GND VDD GPIO_OE[28] OUT_A H2F_A[52]
OUT_B H2F_B[52]
Table 588 • IOMUX CELL 53
I/O Pad Ports
IOMUXCELL Interface
MMUART_0 USB Controller GPIO[29] FPGA Fabric
IN MMUART0_SCK_IN USBC_NXT GPIOB_IN[29] IN_A F2H_GPIN[53]
OUT MMUART0_BAUDOUTN GND GPIO_OUT[29] IN_B F2H_SCP[53]
OE MMUART0_E_MST_SCK GND GPIO_OE[29] OUT_A H2F_A[53]
OUT_B H2F_B[53]
Table 589 • IOMUX CELL 54
I/O Pad Ports
IOMUXCELL Interface
I2C_0 USB Controller GPIO[30] FPGA Fabric
IN SDA_0_IN USBC_DATAI[0] GPIOB_IN[30] IN_A F2H_GPIN[54]
OUT GND DATAO[0] GPIO_OUT[30] IN_B F2H_SCP[54]
OE ~SDA_0_OUT ~NDATAOE GPIO_OE[30] OUT_A H2F_A[54]
OUT_B H2F_B[54]
