Ethernet MAC
UG0331 User Guide Revision 15.0 397
TXCL 0x108 R/W 0x0 This is incremented for each frame that experiences 16
collisions during the transmission and is aborted.
TNCL 0x10C R/W 0x0 This is incremented by the number of collisions experienced
during the transmission of a frame.
TPFH 0x110 R/W 0x0 This is incremented each time a valid PAUSE MAC control
frame is transmitted and honored.
TDRP 0x114 R/W 0x0 This is incremented each time PAUSE frame is honored.
TJBR 0x118 R/W 0x0 This is incremented for each oversized transmitted frame with
an incorrect FCS value.
TFCS 0x11C R/W 0x0 This is incremented for each valid sized packet with an incorrect
FCS value.
TXCF 0x120 R/W 0x0 This is incremented for each valid size frame with a Type Field
signifying a Control frame.
TOVR 0x124 R/W 0x0 This is incremented for each oversized transmitted frame with a
correct FCS value.
TUND 0x128 R/W 0x0 This is incremented for each frame which is less than
64 bytes with a correct FCS value.
TFRG 0x12C R/W 0x0 This is incremented for each frame which is less than
64 bytes, with an incorrect FCS value.
CAR1 0x130 RO 0x0 This indicates the transmit and receive counters and the
receive counters carry the bits. The carry register bits are
cleared on carry register write when the respective bit is
asserted.
CAR2 0x134 RO 0x0 This indicates the transmit counters carry bits. The carry
register bits are cleared on carry register write when the
respective bit is asserted.
CAM1 0x138 R/W 0xFE01FFFF The rollover condition of each transmit and receive counter and
receive counters can be discreetly masked from causing an
interrupt by internal masking.
CAM2 0x13C R/W 0xFFFFF The rollover condition of each transmit counter can be
discreetly masked from causing an interrupt by internal
masking.
Table 338 • EMAC M-SGMII Register Map
Register name
Address
Offset
Register
Type Reset Value Description
SGMII CONTROL 0x00 R/W 0x0 This enables the loopback and the auto negotiation.
The PHY address for the M-SGMII is 0x1E.
SGMII STATUS 0x01 RO 0x0001 This enables the MF PREMABLE suppression enable.
This indicates the auto negotiation complete, associated
PHY auto negotiation ability and link status.
The PHY address for the M-SGMII is 0x1E.
RESERVED 0x02 R/W 0x0 Reserved
Table 337 • EMAC PE-MSTAT Transmit Counters Register Map (continued)
Register
Name
Address
Offset
Register
Type Reset Value Description
