MSS GPIO
UG0331 User Guide Revision 15.0 585
16.4.7.21 IOMUX CELL 31
I/O pad name: SPI1_SS3_MGPIO16A
16.4.7.22 IOMUX CELL 32
I/O pad name: SPI1_SS4_MGPIO17A
16.4.7.23 IOMUX CELL 33
I/O pad name: SPI1_SS5_MGPIO18A
16.4.7.24 IOMUX CELL 34
I/O pad name: SPI1_SS6_MGPIO23A
Table 566 • IOMUX CELL 31
I/O Pad Ports
IOMUXCELL Interface
SPI_1 USB Controller GPIO[16] FPGA Fabric
IN NC NC GPIOA_IN[16] IN_A F2H_GPIN[31]
OUT SPISS_1_OUT[3] GND GPIO_OUT[16] IN_B F2H_SCP[31]
OE SPI_1_MASTER GND GPIO_OE[16] OUT_A H2F_A[31]
OUT_B H2F_B[31]
Table 567 • IOMUX CELL 32
I/O Pad Ports
IOMUXCELL Interface
SPI_1 USB Controller GPIO[17] FPGA Fabric
IN NC NC GPIOA_IN[17] IN_A GND
OUT SPISS_1_OUT[4] GND GPIO_OUT[17] IN_B GND
OE SPI_1_MASTER GND GPIO_OE[17] OUT_A H2F_A[32]
OUT_B NC
Table 568 • IOMUX CELL 33
I/O Pad Ports
IOMUXCELL Interface
SPI_1 USB Controller GPIO[18] FPGA Fabric
IN NC NC GPIOA_IN[18] IN_A GND
OUT SPISS_1_OUT[5] GND GPIO_OUT[18] IN_B GND
OE SPI_1_MASTER GND GPIO_OE[18] OUT_A H2F_A[33]
OUT_B NC
Table 569 • IOMUX CELL 34
I/O Pad Ports
IOMUXCELL Interface
SPI_1 USB Controller GPIO[23] FPGA Fabric
IN NC NC GPIOA_IN[23] IN_A GND
OUT SPISS_1_OUT[6] GND GPIO_OUT[23] IN_B GND
OE SPI_1_MASTER GND GPIO_OE[23] OUT_A H2F_A[34]
OUT_B NC
